Aluminum Alloys



The applications for aluminum alloys are almost limitless.  Choosing an Aluminum alloy for a particular application depends on many factors.  Our Sales Staff can help you with this decision.

Some considerations that should be taken into account are:

1.        Foundry characteristics for the casting process that will be used;

2.        Required mechanical and other properties for the service intended;

3.        Mechanical properties over the service life;

4.        Corrosion resistance for the application;

5.        Machinability, pressure tightness and finishability, if necessary;

Another consideration that should be taken into account is the finished cost of the part.  The following among many other variables can directly affect the cost:

1.        The alloy chosen and the technical requirements of casting that alloy;

2.        Quantity of castings to be produced;

3.        Process used;

4.        Complexity of the shape of the part;

5.        The tooling used for producing the molds;

6.        Dimensional tolerances required;

7.        Inspection and quality standards required



Common Alloys we pour at Bergstrom Foundry:




Typical Mechanical Properties




Tensile Strength
Yield Strength
Elongation
Hardness


psi
psi
 % in 2"
(500 kg load)

319
27,000
18,000
2
70

319-T6
36,000
24,000
2
80

A356
23,000
12,000
6
70

A356-T6
40,000
30,000
6
75

357.0
25,000
13,000
5
-

357-T7
46,000
36,000
3
85

535
40,000
20,000
13
70

705
30,000
17,000
5
-

713
32,000
22,000
3
75

Another consideration that should be taken into account is the finished cost of the part.  The following among many other variables can directly affect the cost:

1.       The alloy chosen and the technical requirements of casting that alloy;

2.       Quantity of castings to be produced;

3.       Process used;

4.       Complexity of the shape of the part;

5.       The tooling used for producing the molds;

6.       Dimensional tolerances required;

7.       Inspection and quality standards required

The applications for aluminum alloys are almost limitless.  Choosing an Aluminum alloy for a particular application depends on many factors.  Our Sales Staff can help you with this decision.

Some considerations that should be taken into account are:

1.       Foundry characteristics for the casting process that will be used;

2.       Required mechanical and other properties for the service intended;

3.       Mechanical properties over the service life;

4.       Corrosion resistance for the application;

5.       Machinability, pressure tightness and finishability, if necessary;

Aluminum Alloy Refrences:

Typical Mechanical Properties:

Common Alloys We Pour:
